Description

Impeller 29040012421 Converter Torque YJSW315-7 29040012411 4110003131 Torque converter SDLG L956F L953F L955F Loader Part

1 箱体 TRANSMISSION HOUSING 29050027231
2 螺栓GB21-M10*30EpZn-8.8 BOLT 4011000017
3 垫圈10 WASHER 29050015481
4 螺栓GB5783-M14*40-10.9 SCREW 4011001127
5 垫圈GB1230-14EpZn-45 PLAIN WASHER 4015000358
6 二档总成 Shaft 29050024791
7 中盖 COVER 29050022981
8 端盖 END PLATE 3030900091
9 密封垫 GASKET 29050011321
10 O形圈GB1235-20*2.4 O-RING 4030000011
11 螺塞 PLUG 3030900102
12 鼓式制动器总成 Brake assembly 29230009952
13 输出法兰总成 FLANGE 29050027361
14 输出轴总成 Output shaft 29050032401
15 输出法兰总成 FLANGE 29050021541
16 销 PIN 29050023122
17 一倒档总成 Planet gear kit 29050032151
18 调整垫片 SHIM 29050025551
19 调整垫片 SHIM 29050020581
20 调整垫片 SHIM 29050020541
21 调整垫片 SHIM 29050020531
22 调整垫片 SHIM 29050020521
23 二轴总成 SECONDARY SHAFT 7200000462
24 超越离合器总成 CLUTCH 29050019471
25 三轴总成 SHAFT 2030900027
26 变矩器总成YJSW315-7 Torque converter 29040012411
27 变矩器总成YJSW315-7 Torque covertor 4110003131
28 滚动轴承GB276-6210N BALL BEARING 4021000019
29 挡圈GB894.1-90-65Mn RETAINING RING 4015000024
30 轴齿轮 DRIVE SHAFT GEAR 29050012701
31 密封垫 GASKET 29050023111
32 滚动轴承GB276-6012 BALL BEARING 4021000012
33 密封垫 Gasket 29050011363
34 螺栓GB16674-M10*55EpZn-10.9 BOLT 4011000855
35 变速泵LG03-BSB-A GEAR PUMP 4120005410
36 调整垫片 SHIM 29050020551
37 调整垫片 SHIM 29050020561
38 调整垫片 SHIM 29050020571
39 调整垫片 SHIM 29050020921
40 调整垫片 SHIM 29050025561
41 吊环螺钉GB825-M20EpZn-20 SCREW 4014000030
42 透气接头 NIPPLE 29050018031
43 螺塞R1/2 Plug 29050033171
44 螺栓GB21-M10*70EpZn-8.8 BOLT 4011000174
45 变速操纵阀LG03-BSF CONTROL VALVE 4120000064
46 密封垫 GASKET 29050011381
47 螺栓GB5783-M18*40EpZn-8.8 BOLT 4011000097
48 垫圈GB93-18-65Mn SPRING WASHER 4015000029
49 连接座 ATTACHMENT BRACKET 29050019321
50 滤油器总成 OIL FILTER 2030900065
51 垫圈8 WASHER 29050015471
52 螺栓GB5783-M8*30EpZn-8.8 BOLT 4011000107
53 压盖 PLATE 29050023011
54 垫圈JB1002-39-T2 WASHER 4015000163
55 接头体 NIPPLE 29050023001
56 环形磁铁LG03-CT70*32*14 MAGNET 4190000007
57 挡圈GB893.1-70-65Mn RETAINING RING 4015000013
58 垫片 SHIM 3030900232
59 螺栓GB5782-M10*80EpZn-10.9 SCREW 4011001013
60 转向泵驱动齿轮 Gear 29050033221
61 滚动轴承GB276-6211 BALL BEARING 4021000020
62 轴承套 BEARING BUSHING 29050000071
63 圆柱堵塞 PLUG 3030900098
64 接头体 NIPPLE 29050018471
65 O形圈GB1235-32*3.1 O-RING 4030000013
66 变速箱通用标牌 NAME PLATE 29050025601
67 铆钉GB827-3*5-BL2 RIVET 4019000012
