Description

SDLG L956F joint shaft pin kits 29250026761 upper shaft pin 29250026811 down shaft pin

10 垫片LGB303-95*160*1 SHIM 4043000040
20 销轴LGB301-95*135NR*250-1401G WELD PIN 4043001471
30 螺栓GB5783-M16*30flZnyc-8.8-480 SCREW 4011001261
40 垫圈LGB001-16flZnyc-480 WASHER 4040000051
50 垫片LGB303-95*150*2 SHIM 4043000038
60 垫片LGB303-95*150*1 SHIM 4043000037
70 销轴LGB301-95*150N*285-1200G Weld pin 4043005822
80 走线胶套 RUBBER SLEEVE 29250001361
90 油管 LUBRICATING PIPE 29250016881
100 销轴LGB301-85*150*290-1A11G WELD PIN 4043001060
110 垫片18*55*10 Shim 29250018651
120 关节轴承GB9163-GE80ES SPHERICAL PLAIN BEARING 4021000243
130 螺栓GB5783-M12*30flZnyc-8.8-480 SCREW 4011001250
140 垫圈GB97.1-12flZnyc-300HV-480 WASHER 4015000428
150 法兰 Flange 29250026791
160 上铰接销 Pin 29250026761
170 塑料塞 PLASTIC PLUG 29270009421
180 下铰接销 Pin 29250026811
190 套 Sleeve 29250026831
200 旋转轴唇形密封圈GB9877.1-B100*125*12 SEALING RING 4030000260
210 螺母GB6177.1-M12flZnyc-10-480 NUT 4013000385
220 螺栓GB16674.1-M12*115flZnyc-8.8-480 Screw 4011001724
230 盘 Flange 29250026851
240 开口垫片4*15*145*0.1 Shim 29250027061
250 开口垫片4*15*145*0.3 Shim 29250027071
260 开口垫片4*15*145*0.5 Shim 29250027081
270 油杯JB7940.1-M10*1 LUBRICATING NIPPLE 4030000065
280 滚动轴承GB297-33216 ROLLER BEARING 4021000244
290 套 Sleeve 29250026841
300 套 Sleeve 29250026861
310 垫片 Shim 29250026871
320 垫片 Shim 29250026881
330 垫片 Shim 29250026891
340 开槽螺母 NUT 29250017691
350 开口销GB91-8*80EpZn-Q235A SPLIT PIN 4016000043
360 螺栓GB5783-M10*35flZnyc-8.8-480 SCREW 4011001270
370 垫圈GB96.1-10flZnyc-300HV-480 WASHER 4015000426
380 减震垫 DAMPER MAT 11220538
390 钢管 STEEL PIPE 11220539
400 护套LGB313-20*32 RUBBER SLEEVE 4043001362
410 螺栓GB5783-M10*25flZnyc-8.8-480 SCREW 4011001248
420 右灯架 Lamp bracket 29250028511
430 走线胶套 RUBBER SLEEVE 29250008461
440 螺栓GB16674-M12*25flZnyc-8.8-480 SCREW 4011001240
450 转向销轴 PIN 29250018341
460 右前挡泥瓦 FRONT FENDER 29250010901
470 螺栓GB5783-M10*40flZnyc-8.8-480 SCREW 4011001280
480 防松套LGB331-10*20*16flZnyc-45 Attaching sleeve 4043002603
490 前盖板 Plate 29250026331
500 垫片 SHIM 29250000301
510 通油螺栓 BOLT 29250000291
520 左前挡泥瓦 FRONT FENDER 29250010881
530 左灯架 Lamp bracket 29250028481
540 接头 NIPPLE 29250014121
550 管夹 CLAMP 29250000311
560 垫圈GB93-6EpZn-65Mn WASHER 4015000213
570 螺钉GB818-M6*10flZnyc-4.8-480 SCREW 4014000510
580 油管 Lubricating pipe 29250021041
590 油管 Lubricating pipe 29250024251
600 油管 Lubricating pipe 29250024381
610 开口垫片4*15*145*1.0 Shim 29250027161
